序号 |
型号 |
结构 |
材料 |
侧板径d1 |
筒径d2 |
孔径d3 |
内宽L2 |
全长L1 |
侧板 厚S |
携行孔 |
备注 |
|
r |
e1-e2 |
|||||||||||
1 |
PN1250 | 组合 | ABS | 1250 | 610 | 80、127 | 800 | 900、950 | ||||
2 |
PL610 | 对插 | PP发泡 | 610 | 300 | 80 | 320 | 380 | 30 | |||
3 |
PC710 | 对插 | PP发泡 | 710 | 500 | 51,127 | 180 | 250 | 35 | |||
4 |
PL800C | 对插 | PP发泡 | 800 | 400 | 80 | 450 | 530 | 40 | |||
5 |
PC132 | 整体 | ABS/PS | 132 | 55 | 20 | 67 | 90 | 11.5 | |||
6 |
PC560A | 组合 | ABS | 560 | 315 | 127 | 280 | 355 | 37.5 | |||
7 |
PC500B同扁线专用盘 | 半体旋焊成型 | ABS/PP | 500 | 300 | 36/40/51/56/80/127/133 | 190/250/310 | 250/310/370 | 30 | |||
8 |
PC600A铜扁线专用盘 | 半体旋焊 | ABS/PP | 600 | 400 | 133 | 280 | 340 | 30 | |||
9 |
PC610铜扁线专用盘 | 半体旋焊 | ABS/PP | 610 | 300 | 50/80 | 240/320 | 300/380 | 30 | |||
10 |
PC710B铜扁线专用盘 | 半天旋焊 | abs/pp | 710 | 500 | 51/127 | 180/245/310 | 250/315/380 | 35 | |||
11 |
PC110B | 整体 | ABS | 110 | 70 | 19 | 78 | 97 | ||||
12 |
汇流带专用盘研发成功 | PCK165 | ABS/PS | 165 | 74 | 25 | 90 | 134 | ||||
